Barco Medical Surgical 24 Inch High Def LCD Display with HDSDI In/Out
$4,560.00
Discontinued Product. Please see the navigation bar to the left for the latest Barco Selection.
The 24-inch MDSC-2124 is a near-patient surgical display that uses widescreen (16:10) LCD technology featuring full High Definition resolution (1920 x 1200). Thanks to the bright, high-resolution LCD panel, surgeons performing a surgical procedure using high-definition endoscopy cameras are presented with stunning panoramic views and improved depth perception.
Discontinued Product
MASTER DISTRIBUTOR
24X7 SUPPORT
COMPETITIVE PRICING
SAME DAY SHIPPING
VALUABLE CONSULTATION
Featuring broad input connectivity, the MDSC-2124 offers a versatile display solution for HD endoscopy cameras, room and boom cameras, ultrasound, PACS and patient information.
The MDSC-2124 offers the fastest image transmission and the highest broadcast quality imaging available today. Enhanced with Barco’s outstanding image processing algorithms, such as motion adaptive de-interlacing and noise reduction, the MDSC-2124 delivers artifact- and lag-free images at all times.
24″ wide-screen LCD featuring full HD (1920 x 1200)
• Advanced image processing algorithms
• High brightness (500 cd/m2)
• Wide input connectivity for maximum flexibility
• Color accurate images at different viewing angles
Technology TFT Active Matrix LCD
Resolution 1920 x 1200
Active screen diagonal 24 inches (611 mm)
Active screen area 20.5 x 12.8 inches (518 x 324 mm)
Pixel pitch 0.294 mm
Brightness 500 cd/m2
Contrast ratio 1000:1
Aspect Ratio 16:10
Viewing angle 178 degrees
Response time 8 ms (gray to gray)
Display functions Gamma, DICOM
Colors 16.8 million
Inputs DVI-I, VGA (D15), RGBS (4BNC), S-Video, Composite video, Component video (4BNC) SDI/HD-SDI (Input and active loop-through output)
Supported resolutions
* On composite, S-video and component inputs: PAL-Secam 576i, NTSC 480 i/p
* On DVI, VGA and RGBS inputs: VGA up to WUXGA, HDTV 720p and 1080 i/p
* On SD/HD-SDI input: 480i, 576i, HDTV 720p and 1080i
Control RS232 (9pin D-sub), On Screen Display (OSD)
External DC Power Supply 90-264 VAC
Display power 20-24 VDC
Power consumption 100 Watt max
Operating temperature range 41° to 104° F (0° to 40° C)
Humidity Max. 85%
Mounting 100 mm VESA
Dimensions 22.9 x 15.5 x 4.3 inches (583 x 393 x 108 mm)
Weight 23.6 lbs (10,7 kg)
Regulation Compliance UL 60601-1, EN60601-1, CE, c-UL, KETI, PSE EMC, FCC-B, EN 60601-1-2, ICES-001, KETI, VCCI, CCC, IPX2
Optional accessories Table stand
List Price – $4,560.00
