NEW! JVC 2MP 21.3 Clinical Review Display – CL-R211
$1,995.00 $996.00
JVC CL-R211 (CLR211) 2MP 21.3” Clinical Review Display is an optimal solution where doctors need to view both grayscale and color images, and effectively covers multiple applications like PACS, CAD, PET and nuclear medicine.
Dynamic Gamma — One Pixel Based Contrast and Brightness, Gamma.
Call for Best Price!
JVC CL-R211 (CLR211) 2MP 21.3 Clinical Review Display
With the JVC CL-R211 (CLR211) Color images are automatically recognized to provide optimized contrast, brightness, and gamma. No user intervention is required.
Auto Text Mode — Auto-Brightness Blinding Mode for Text Area
Automatic brightness control for text data to reduce eye strain for patient lists and reporting applications.
LED Backlight for Image Stability and Energy Saving
Compared to the conventional CCFL backlight models, JVC CL-R211 (CLR211) with LED backlight system saves energy and will hold brightness much longer. Additionally, a mercury-free LED backlight contributes to reduce environmental impacts.
Built-in Sensor
With two built-in sensors for luminance stabilization and ambient light measurement, JVC CL-R211 consistently delivers unmatched image quality.
Ambient light sensor
An ambient light sensor is built-in so that calibration appropriate for the effects of ambient luminance is carried out.
Luminance sensor
The luminance sensor attached in front of the screen constantly monitors and accurately stabilizes luminance on the screen surface by sending feedback to the control circuit.
Remote Calibration
DICOM conformance check and calibration can be remotely performed. These remote management features will minimize the burden of system administrators.
Optional PM Medivisor software is required.
DICOM Conformance Check
User-friendly OSD functions include the DICOM conformance check function.
Display Quality Control
The Medivisor Series software is a user-friendly tool to effectively manage JVCKENWOOD’s displays. Calibration software Medivisor Nx, quality assurance software QA Medivisor and performance monitoring software PM Medivisor interact closely with each other to help system administrators easily manage all JVCKENWOOD’s displays in the network.
DisplayPort
The JVC CL-R211 (CLR211) implemented Display Port with 10-bit depth color in addition to conventional DVI input and achieved 1billion 64 million simultaneous colors with 10-bit input.
Uniformity Equalizer
The luminance uniformity correction system will produce stable images across the screen.
User-selectable Display Configurations
Luminance/gamma settings are selectable from three preset levels according to the needs. The user-selectable configuration enables stress-free operations without specialized settings.
OSD Information Display
With a push of a button, the display’s current status can be checked such as the display model, total operating time, actual measurement of luminance, and calibration settings.
Display Status Indicator
The current display operating status can easily be checked by the front LED indicator.
Worldwide Medical Safety Standards
JVC CL-R211 meets worldwide medical safety standards.
About JVC-Kenwood
JVC-Kenwood is a leading worldwide manufacturer of medical image displays and touch panel displays. Its high-end, high-cost-performance medical image displays and touch panels are backed by its unique technology and know-how through decades of solid experience in the industry since 1972.
JVC-Kenwood has supplied computer displays for factories, broadcast stations, workstations, and other applications, and has earned high marks for its product reliability under harsh conditions and post-installation support, not to mention specialized technologies required for respective fields.
JVC-Kenwood continues to provide high-performance displays for specialized fields by developing leading-edge technologies while providing consistently optimal customer service.
SPECIFICATION
Model Name
- CL-R211
LCD Panel
- Technology
- 21.3″ color TFT IPS technology
- Display Area
- 324 mm x 432 mm
- Pixel Pitch
- 0.270 mm x 0.270 mm
- Contrast Ratio
- 1800:1(typ.)
- Maximum
Luminance - 500cd/㎡(typ.)
280 cd/㎡ ・ 250 cd/㎡ (calibrated)
- Viewing Angle
- 178° vertical and horizontal
Visual Performance
- Native Resolution
- 1200×1600
- Display Colors
- 16.77 million colors from a palette of 68 billion colors
1.07 billion colors with DisplayPort and 10-bit viewer
Interface
- Input Signal
- DVI-D(DVI 1.0 compliant)
DisplayPort(DisplayPort 1.2a compliant)
- Plug and Play
- DDC2B compliant
Input Power Supply
- Input Power Supply
- 100V-240V 50/60Hz
- Maximum Power Consumption
- 45W(typ.)
Features
- Calibration Control
- Luminance,Gamma,Color temperature
Capable of storing 3 sets of LUT
(Optional Calibration Kit is required)
- OSD Information Display
- Model name, Serial No., Total operating time,
Calibration settings (Operating time since last calibration, Luminance, Gamma),
Current luminance, Color temperature and Ambient light, DICOM conformance
- USB Hub
- USB Rev. 2.0 compliant, Self-powered
USB upstream connector (x1),
USB downstream connector (x2)
- Other Features
- Uniformity Equalizer, Hardware pivot, LED indicator, DisplayPort Daisy Chains,
Advanced power management, Human Presence Sensor, Dynamic Gamma,
Auto Text Mode, Luminance stabilization, Multiple LUT, Self DICOM check, Self-calibration
Approvals
- ANSI/AAMI ES60601-1(2005)+A1(2012), CAN/CSA-C22.2 No.60601-1(2014), CE(EN60601-1, EN60601-1-2),
RCM, FCC Part15 subpart B Class B, ICES-003-B, VCCI-B, FDA510(k), J-Moss, RoHS, EAC
Physical Characteristics
- Dimensions
(W × H × D) - Landscape: 493 mm × 451.3 / 546.3 mm × 196.5 mm
Portrait: 361.5 mm × 517 / 612 mm × 196.5 mm
- Weight
- 8.9 kg
- Tilt Stand
- Tilt, Swivel, Portrait / Landscape
- Mount
- VESA standard (100 mm x 100 mm)
- Security Slot
- Anti-theft security slot
Accessories
- Power cord, DVI cable, DisplayPort cable, USB cable, Operation manual,
Installation manual, Software(QA Medivisor Agent LE)
DIMENSIONS
OPTIONS
CL-R211
- Graphics cards
- CAL-016 (Calibration Kit)
Calibration and QA testing software and Calibration sensor
- PM Medivisor (PM-001A)
Display performance monitoring software
- QA Medivisor
Acceptance and constancy testing software
- Medivisor Nx
Calibration software
