LG 27HS714S-W 27″ 4K Mini-LED Surgical Monitor

LG 27HS714S-W 27-inch 4K Mini-LED Surgical Display Monitor

LG 27HS714S-W 27-inch 4K Mini-LED Surgical Monitor.

Outstanding Image Quality with LG Mini-LED Technology

1.5K Local Dimming Zones
Boasting the exceptional picture quality of LG Mini-LED technology, the LG 27HS714S-W provides brilliant and true-to-life images with a high level of detail, allowing surgeons to experience an immersive environment to focus clearly on the surgical procedure. Local Dimming, inherent to Mini-LED technology, enables precise brightness control across the entire LED backlight, enhancing visual contrast by darkening the dark areas and brightening the light areas. This monitor, equipped with 1.5K Local Dimming zones, significantly enhances the dynamic contrast ratio up to 1,000,000 : 1 and reaches a peak brightness up to 2,000 cd/m². Additionally, the Local Dimming technique used in this Mini-LED monitor may improve energy efficiency compared to traditional edge-lit backlight technologies, thereby prolonging the life of the display.

Expanded Color Reproduction
With a wide color range of DCI-P3 98%, the LG 27HS714S-W provides a great level of detail with optimized image clarity and enhanced color response.

LG 27HS714S-W is Suitable for Surgical Environments

Optical Bonding
The LG 27HS714S-W is engineered with optical bonding technology, seamlessly integrating the backlight, module, and glass without any air gaps, further enhanced with Anti-Glare, Anti-Reflection, and Anti-Fingerprint coatings on the front glass. This combination significantly improves display readability by minimizing reflections and glare, ensuring that image clarity and color response are optimized even in brightly lit environments.

IP45 (front) & IP32 (except for front) & IK06
With IP45 (front) and IP32 (except for front) ratings, the LG 27HS714S-W is suitable for surgical environments where blood and other bodily fluids are likely to splash. Additionally, this monitor offers resistance to physical impact, as denoted by its IK06 rating.

12G-SDI Support
The LG 27HS714S-W supports 12G-SDI, which enables longdistance transmission of 4K signals over a single coaxial cable.

Lightweight Design
Weighing only 21.3 lbs, this surgical monitor is suited for mounting on surgical arms and pendants.

User Convenience

Up to 4 PBP & PIP
The LG 27HS714S-W supports both 4PBP (Picture-by-Picture) and PIP (Picture-in-Picture), allowing it to display input from up to four different sources simultaneously or overlay one input on another. These features enable medical professionals to monitor various critical information streams concurrently on a single screen, enhancing operational efficiency and decision-making. For example, using the LG 27HS714S-W, medical staff can view a combination of laparoscopic and endoscopic images while monitoring vital signs.

Clone Screen
The LG 27HS714S-W features a Clone Screen function that replicates the entire display content onto a secondary monitor, even with advanced settings like PIP or PBP. The Clone Screen functionality is facilitated through the HDMI output. By using Clone Screen, surgical team members can visually monitor the progress of the surgery, which can help facilitate efficient collaboration and communication.

Mirror Mode & Rotation Mode
Mirror Mode and Rotation Mode allow users to adjust the display for optimal viewing, whether flipping the image horizontally or rotating it 180 degrees to match the orientation of the surgical camera.

Failover Input Switch
The Failover Input Switch feature on this monitor ensures uninterrupted video signal by automatically switching to an alternative video source if the primary input fails. This function is compatible across all interfaces, including HDMI, SDI, DVI, and DP, offering flexibility in setup and redundancy in signal sources. Particularly for 12G-SDI, the system can automatically switch from the primary input to the next available input if a signal loss is detected. This seamless transition between inputs minimizes disruptions and ensures consistent video output, essential for surgical applications where continuity and image clarity are critical.

Model: 27HS714SW
